4.6.3 Skip equipment or points in a route
1. To skip equipment in a route, press F8 Next Equip on the Route Data Collection
screen.
The equipment listed at the top of the screen changes.
2.
To skip a measurement point, press F7 Next Point on the Route Data Collection
screen.
The measurement point listed at the top of the screen changes.
4.6.4 Label equipment as out of service
This label indicates the equipment is shutdown and you could not collect data. The
analyzer applies the label to all measurement points on the equipment and does not let
you collect data. When you transfer the route back to AMS Machinery Manager, the label is
included with the route.
Procedure
1. Activate a route.
2. Ensure the desired equipment is displayed in the route.
3. On the Route Data Collection screen, press ALT > F3 Out Of Service.
The Status field changes.
4. To remove the label, press F3 Out of Service again.
4.6.5 Add or delete a field alert
A field alert places a warning message in the Status field on the Route Data Collection
screen. The field alert is saved with the measurement point and is a reminder to perform
special analysis in AMS Machinery Manager.
When you add a field alert, any previous status messages are removed.
Procedure
1.
Activate a route.
2. Ensure the desired measurement point is displayed.
3. From the Route Data Collection screen, press F10 Field Alert.
The Status field displays FIELD ALERT if you collected data on the point. If you did not
collect data, FIELD ALERT displays after you collect data.
4. To remove the field alert, press F10 Field Alert again.
