Note
The audio is not stored or recorded.
Prerequisites
Pair a Bluetooth device. See Section 2.11.2.
Procedure
1.
From the Route Data Collection screen, press F6 Listen To Live Data. You can also
access F6 Listen To Live Data from a waveform or spectrum plot screen.
The Bluetooth Listener screen appears.
2. Set up the following options as necessary.
Option Description
F1 Volts Accel Set the audio signal to use the Accel or the Volts input. The default is the
input for the active measurement point when you selected Listen To Live
Data.
F2 Input Set the audio signal to use an input channel (A, B, C, D). The default is the
input for the active measurement point when you selected Listen To Live
Data.
F6 Test Headset Test the Bluetooth communication between the analyzer and the
headphones. Use your headphones to listen to the sound that is generated
for several seconds.
F8 Filter Set the filter for the audio signal. You can select Off (no filter), 2000 Hz High
Pass, or 8000 Hz High Pass.
F9 Gain Increase the amplitude of the audio signal. The signal gain affects the
volume. You can also use the up arrow key.
F10 Gain Decrease the amplitude of the audio signal. The signal gain affects the
volume. You can also use the down arrow key.
F12 Mute Mute or unmute the audio.
3. Press F4 Acquire Data to begin listening and collecting data.
You can now listen to the vibration signal. The Home key is disabled while you are
listening to data.
4.
To stop the listening mode, press Enter or Back and go to the Comm Setup option on
the Home screen to disable the radio.
4.6.2 Redo a measurement
1. From the Route Data Collection screen, select the desired point.
2. Press F9 Start Acq or Enter.
The analyzer collects new data.
