Procedure
1.
Use the appropriate cable to connect your analyzer to a computer where AMS
Machinery Manager is installed.
2. On the computer, open Data Transfer.
3. On the analyzer, press the Connect For Transfer option in the program for the desired
job.
Program Key sequence to Connect for Transfer option
Analyze Home > F7 Analyze > ALT > F9 Connect For Transfer
Balance Home > F9 Balance > F12 Job Manager > F7 Connect For Transfer
ODS/Modal Home > F12 ODS/Modal > F8 Job Manager > F7 Connect For Transfer
Transient Home > F11 Adv. Transient > F8 Job Manager > F7 Connect For Transfer
The analyzer connects to AMS Machinery Manager.
4.
To transfer the job using AMS Machinery Manager:
a. Select the appropriate database in the Navigation - Data Transfer pane.
b. Drag and drop or copy and paste the desired job to the database in the Data
Transfer tab.
The Data Transfer Notification pane displays the progress of the transfer.
5. To transfer the job using the analyzer:
a. Press F8 Dump Data.
The analyzer lists the default database at the top of the screen.
b. Select one or more jobs you want to transfer, and press F1 Select.
c. To send the jobs to a different database, press F6 Clear Database Info.
d. Press F7 Begin Data Dump.
e. If prompted, select a database and an area in the database, and press F4 Select
Area.
f. If prompted, select the desired equipment, and press F7 Select.
6. After transfer completes, press the Back key to disconnect from AMS Machinery
Manager and return to the program's Job Manager or ALT2 screen.
3.4.5 Dump a route from the analyzer to AMS Machinery
Manager
Unless you specify a different database, the analyzer transfers the route back to the same
database, area, equipment, and measurement.
