Note
This operation may take several hours.
Procedure
Press Home > ALT > F4 Memory Utility > F3 Clean Disk.
Clear the internal settings
You can clear the internal settings of the analyzer that are stored in permanent memory.
The default settings are loaded the next time you turn on the analyzer.
CAUTION!
Do this operation only if instructed by technical support.
Procedure
1.
Press Home > ALT > F4 Memory Utility > F8 Erase PReg.
2. Press Enter.
Format the internal memory
Formatting the internal memory erases all data and programs in the analyzer. When the
formatting is complete, the analyzer shuts down. The internal memory includes programs
like Route, Analyze, and Balance. All routes, jobs, and data are erased.
Procedure
1. Press Home > ALT > F4 Memory Utility > F9 Format Disk.
2. Press Enter.
2.12.3 Battery Utility
The Battery Utility on the Home ALT2 screen lets you view detailed information about the
battery pack, including the remaining charge and battery voltage.
View the battery status
1.
Press Home > ALT > F5 Battery Utility.
The screen indicates if the analyzer is running on battery power or the power supply.
2. Press F3 Show Details for additional diagnostic information, if necessary.
The charge and voltage level decreases as the battery discharges.
Note
Approximate values are displayed and they should be used only as a guideline.
Introduction to the analyzer
