2.9.4 Print routes and jobs to AMS Machinery Manager or a
memory card
You can enable or disable printing on the analyzer. When printing is enabled, you can send
routes, jobs, and summary reports to AMS Machinery Manager or an inserted SD (Secure
Digital) memory card. By default, the analyzer can send files to AMS Machinery Manager.
Procedure
1.
Press Home > ALT > F2 General Setup > F6 Set Print Mode.
2. Use the up and down arrow keys to select an option.
Option Description
Send to PC Send files to AMS Machinery Manager. Files can include routes, jobs,
screen captures, splash screens, or summary reports. The default is
Send to PC.
Store as BMP on CARD Save the file as a .bmp to the SD memory card.
Store as JPG on CARD Save the file as a .jpg to the SD memory card.
Print Off Disable printing. Print options, such as the F7 Connect For Printing
option on the Home ALT2 screen, are not available.
3. Press Enter.
2.9.5 Set the low-battery warning level
When the battery pack discharges to the specified percent, the analyzer displays a
message telling you to recharge the battery pack.
Procedure
1.
Press Home > ALT > F2 General Setup > ALT > F3 Set Warning Level.
2. Enter a percent between 0 and 99.
A 0 disables this feature. The default is 15 percent.
3. Press Enter.
2.9.6 Configure the power key
You can set the number of seconds you must hold the power key to shut down the
analyzer. This option does not change the hold time to put the analyzer in standby.
Increase the number of seconds to prevent users from accidentally pressing the power key
and shutting down the analyzer.
Procedure
1. Press Home > ALT > F2 General Setup > ALT > F4 Set Hold Time.
2. Enter a number between 1 and 5 seconds.
Introduction to the analyzer
22
