Procedure
1.
Press Home > ALT > F2 General Setup.
2. Press F2 Set Keypad Beeper to enable or disable the sound when you press a key.
3. Press F3 Set Status Beeper to enable or disable sounds for alerts and status indicators.
4. Press Enter.
2.9.2 Set the standby timer
To conserve battery pack power, set the timer to automatically put the analyzer in standby
after a period of inactivity, such as no data collection or key presses. Standby is similar to
the standby mode on a computer. The analyzer is powered on, but the backlight is off to
conserve battery power. The standby timer also shuts off the keypad backlight. The
standby timer is disabled when the power supply is connected to and powers the analyzer.
The blue LED displays on the front of the analyzer when the analyzer is in standby. To leave
standby, quickly press the power key.
Note
After 60 minutes in standby, the analyzer shuts down. You do not lose any data when this occurs.
Procedure
1.
Press Home > ALT > F2 General Setup > F4 Set Standby Time.
2. Enter the number of minutes between 0 and 30.
A 0 disables this feature. The default is 10 minutes.
3. Press Enter.
2.9.3 Set the backlight timer
To conserve battery pack power, set the timer to automatically turn off the backlight after
a specified period of inactivity, such as no data collection or key presses. After the timer
expires and the backlight is turned off, press a key or the screen to turn on the LCD
backlight and reset the timer. The timer is disabled when the power supply is connected to
and powers the analyzer.
Unlike standby mode, the blue LED on the front of the analyzer does not display when the
backlight is off.
Procedure
1.
Press Home > ALT > F2 General Setup > F5 Set Backlight Time.
2. Enter the number of seconds between 0 and 120.
A 0 disables this feature. The default is 30 seconds.
3. Press Enter.
