A.3 Input specifications
Input signals
A 2-milliampere, 20-volt (nominal), constant-current power supply inside the analyzer
powers sensors, such as accelerometers, connected to the accelerometer channel inputs.
Full scale input level
Accel channels A, B, C, D
Volts channels A, B, C, D
Accelerometer input 0-20 V Full scale vibration level is +/- 90 g's when using a 100-mV/g
accelerometer
Volts input -20 V to +20 V
Input impedance Greater than 125K ohms
Input signal types
Dynamic signals Single channel /dual channel/four channel
DC signals Single channel/dual channel/four channel
RPM/tach signal TTL pulse
Keypad entry Full alphanumeric capability
In-field route analysis tools
Fault frequency
overlays on plot
Identifies source of vibration peaks
Parameter trends Up to 12 parameters trended over 2+ years
Colored alarms Shows specific parameter in alarm and percentage of alarm value
Waveform
autocorrelation
Identifies whether impacting is periodic or random
Input sensor types
Portable sensors Accelerometers, velocity probes, RPM/tachometer probes, temperature
sensors, flux coil, current clamp, pressure sensors, triaxial accelerometers,
impact hammer
Installed sensors Any vibration or dynamic sensor with a voltage output; any DC-type signal
