Appendix A
Technical specifications
Topics covered in this appendix:
• Hardware specifications
• Measurement specifications
• Input specifications
• Connecting to a computer
• Waste Electrical and Electronic Equipment
A.1 Hardware specifications
Physical dimensions
Dimensions 8.8" (248 mm) high, 1.57" (40 mm) deep, 8.9" (226 mm) wide
Weight 3.95 lbs (1.79 kg)
LCD display 6" x 4.5" (151 x 115 mm) color TFT w/ LED backlight. Resolution
640 x 480 pixels. Touchscreen - XY resistive
Keypad Tactile Dome buttons, 12 tactile dome buttons with backlit keys,
Electroluminescent panel illumination.
Built-in stand
Environmental limits
Operating temperature -4° to 122° F (-20° to 50° C)
Long-term storage
temperature
-4° to 95° F (-20° to 35° C) with battery
Storage at elevated temperatures will significantly reduce battery
life.
Long-term storage
temperature
-40° to 150° F (-40° to 65° C) without battery
Environmental rating Sealed enclosure, IP-65 rated
Battery pack
Type Rechargeable Lithium-Ion battery pack
Volts 7.2 volts (Nominal) protected output
LEDs On pack LED readout
Capacity 10+ hours of continuous use
