Note
When the job has discrete weight positions and you import from the Balance Correction screen, the
analyzer converts the discrete positions to continuous positions.
Procedure
1.
From the Balance main menu, press ALT > F6 Calculator Mode > F5 Static Couple Analysis.
2. Set the following options as necessary.
Option Description
F2 View Balance
Corr.
View the last calculated balance correction. This option displays only if the
analyzer calculated a balance correction, you accessed Static/Couple Analysis
from the Trim Run Applied Weight menu, and you defined two weight
planes for the job.
F3 Plane #1
Weight
Enter the calculated correction weight up to10,000. The default is 0. You
can also import this value from the Balance Correction menu. This field is
unitless. If you access Static/Couple Analysis from the Trim Run Applied
Weight screen, the units are as defined for the job.
F4 Plane #1
Angle
Enter the calculated correction angle in degrees. The default is 0. If you
import discrete weight positions (Advanced Mode only) from the Balance
Correction menu, the analyzer converts them to continuous positions.
F9 Plane #2
Weight
Enter the calculated correction weight up to 10,000. The default is 0. You
can also import this value from the Balance Correction menu. This field has
no units. If you access Static/Couple Analysis from the Trim Run Applied
Weight screen, the units are as defined for the job.
F10 Plane #2
Angle
Enter the calculated correction angle in degrees. The default is 0. If you
import discrete weight positions (Advanced Mode only) from the Balance
Correction menu, the analyzer converts them to continuous positions.
3. Press F1 Calculate Solution or Enter.
The Static/Couple Analysis Solution screen displays the newly calculated weight
locations. For the Static Vector solution, the plot represents a weight plane with
continuous weight positions. For the Couple Vectors solution, the plot for each
weight plane displays continuous weight positions or discrete weight positions as
defined under Job Setup.
4.
If you accessed Static/Couple Analysis from a trim run, press F11 Insert Static Solution or
F12 Insert Couple Solution to send the calculated solution to the Trim Run Applied
Weight entry.
The analyzer splits the weight evenly between the two weight planes for the static
solution.
5. Press F7 Static Couple Calc. to exit and return to the calculation screen.
Balance
235
