Procedure
1.
From the Balance main menu, press ALT > F6 Calculator Mode > F4 Adjust Fixed Weights.
2. Set the following options as necessary.
Option Description
F2 View Balance
Corr.
View the last calculated balance correction. This option displays only if the
analyzer calculated a balance correction, and you accessed Adjust Fixed
Weights from the Trim Run Applied Weight menu.
F3 Enter Desired
Weight
Enter the desired weight up to 10,000. The default is 0. You can also
import the value from the Balance Correction menu. You cannot import
discrete positions. This field is unitless. If you access Adjust Fixed Weights
from the Trim Run Applied Weight screen, the units are as defined for the
job.
F4 Enter Desired
Angle
Enter the desired location (typically the calculated correction angle) for
the weight in degrees. The default is 0. You can also import the value from
the Balance Correction menu, but the analyzer does not allow discrete
positions (Advanced Mode only).
F9 Available
Weight #1
Enter the first available weight between 0 and 10,000. The default is 0.
This field is unitless. If you access Adjust Fixed Weights from the Trim Run
Applied Weight screen, the units are as defined for the job.
F10 Available
Weight #2
Enter the second available weight between 0 and 10,000. The default is 0.
If you access Adjust Fixed Weights from the Trim Run Applied Weight screen,
the units are as defined for the job.
3. Press F1 Calculate Solution.
The Adjust Fixed Weight Solution screen displays the newly calculated weight
locations. To change the rotation direction on the plot, press F6 Toggle Direction
Rotation.
4.
If you opened Adjust Fixed Weights from a trim run, press F12 Insert to Trim Weight to send
the calculation solution to the Trim Run Applied Weight entry.
5. Press F7 Adj. Fxd. Weights Calc. to exit and return to the calculation screen.
9.15.4 Calculate weight placement using static and couple
components
The Static/Couple Analysis option lets you enter two known weights and angular locations,
such as the correction results, to have the program separate the static and couple
components. Static/Couple Analysis lets you calculate the weight placement to address the
static and couple components of the imbalance.
Static/Couple Analysis is only available when the job has two measurement planes.
