Option Description
F6 Program Manager Update the programs, add new programs, delete unused programs, or
change the splash screen. A password is required to delete programs.
F7 Analyze or Adv.
Analyze
Collect data using predefined measurements called Analysis Experts, or
create your own measurements in Manual Analyze.
F8 Route Collect data using a route created in AMS Machinery Manager. You cannot
create or modify routes on the analyzer.
F9 Balance Balance a machine. Balance is an optional program that you load onto the
analyzer.
F10 Intentionally blank.
F11 Adv. Transient Collect large, unbroken time waveforms similar to a digital recorder.
Advanced Transient is an optional program that you load onto the analyzer.
F12 ODS/Modal Collect cross channel data for animated analysis of a machine. ODS/Modal is
an optional program that you load onto the analyzer.
ALT2 keys
Option Description
F1 Version View the versions of the firmware and programs installed on your analyzer.
F2 General Setup Modify settings for the analyzer screen, keys, and print functionality.
F3 Set Time Set the time and date in the analyzer.
F4 Memory Utility View information about the internal memory.
F5 Battery Utility View information about the battery pack.
F6 View Error Log View information about any errors the firmware generated.
F7 Connect For
Printing
Connect to AMS Machinery Manager to print files or screen captures.
F8 Intentionally blank.
F9 Intentionally blank.
F10 Intentionally blank.
F11 Intentionally blank.
F12 Intentionally blank.
2.7.1 Return to the Home screen
Press the Home key on the front of the analyzer.
Introduction to the analyzer
