Option Description
F3 Meas. Points Enter a number between 1 and 8 and press Enter. The maximum number
depends on the number of measurement planes.
F8 Enter Balance
Spec.
Enter a value between 0.001 and 10,000 for the desired vibration level for
the equipment, and press Enter. The units are the same as the sensor.
F9 Select Weight
Units
(Optional)
Select the trial and trim weight units for the job. The Balance program
displays this unit wherever a weight displays. You cannot change this value
after any trial run data is acquired.
Note
Weight Units are only a reference for UltraBal reports or future setups. The
analyzer does not use weight units to calculate the balance correction.
F10 Tach Config. Set up a tachometer or open a saved configuration. See Section 9.3.4 for
details.
F11 Speed Setup (Optional)
Enter a number between 1 and 6 to set the number of equipment speeds
(RPM), and set the valid range for collecting data using Delta RPM, which is
used for all speeds. See Section 9.3.5 for steps.
The number of measurement points multiplied by the number of
measurement speeds cannot exceed 24.
Note
The analyzer does not use speed to calculate the balance correction.
4. From the Job Setup screen, press Enter.
In Basic Balance mode, the Acquire Data screen appears and you are ready to collect
data. In Advanced Balance mode, the Measurement Plane Setup screen appears.
Postrequisites
In Advanced Balance mode, set up the measurement plane. See Section 9.5.
9.3.3 Set up a multiple-plane balance job
1. From the Balance main menu, press F3 Job Setup.
The Job Setup screen appears.
2.
In Basic Balance mode, set the following options.
Balance
193
