• You cannot view the reference run data or last set of trim run data from the trial run.
Change the mode
You can change the mode for a job at any time. When you change the mode, the setup
parameters reset to their default values and any data stored in the job is deleted.
Note
Unless noted, all information in this manual pertains to both the Basic and Advanced Modes.
Set the balance mode
Note
Changing the balance mode clears the current job and starts a new job.
Procedure
1.
From the Balance main menu, press F3 Job Setup > F7 Balance Mode.
Each time you press F7 Balance Mode, the mode changes.
2. Press Enter.
9.3.2 Set up a single-plane balance job
1. From the Balance main menu, press F3 Job Setup.
2. In Basic Balance mode, set the following options.
Option Description
F2 Toggle Config. Press F2 to select 1 plane, 1 sensor or 1 plane, 2 sensors.
F8 Enter Balance
Spec.
Enter a value between 0.001 and 10,000 for the desired vibration
level for the equipment, and press Enter. The units are the same as the
sensor.
F10 Tach Config. Set up a tachometer or open a saved configuration. See Section 9.3.4
for details.
F12 Sensor Setup Set up the type of sensor, the sensor parameters, or a multiplexer. See
Section 9.4 for details.
3. In Advanced Balance mode, set the following options.
Option Description
F1 Weight Planes Enter 1 and press Enter.
F2 Meas. Planes Enter a number between 1 and 8 and press Enter.
Balance
192
