8.10 Print an ODS/Modal plot to a memory card
You can save a plot to a memory card if you inserted a card into the analyzer. See
Section 2.10.1 for more information.
Prerequisites
On the analyzer, press Home > ALT > F2 General Setup > F6 Set Print Mode and ensure the
default print mode is set to Store as BMP on CARD or Store as JPG on CARD.
Procedure
1.
Display your plot in ODS/Modal.
You can press F7 Display Data on the ODS/Modal main menu, or collect data and view
the plot.
2. Press F7 Print Plot.
3. Enter up to 8 characters for a file name.
4. Press Enter.
The analyzer begins creating and saving the file to the memory card. The progress is
displayed on the screen.
