8.7.6 Copy ODS/Modal data
Copy data stored on one measurement point/direction to another measurement point/
direction. Use this option if you could not mount a sensor at a location, and you assume
the vibration is the same for other points.
Procedure
1.
Select the measurement point to copy.
2. From the ODS/Modal main menu, press ALT > F9 Copy Data.
3. Press F10 Paste From to paste the data to another measurement point.
4. Press Enter.
8.8 Display the data for a measurement point
1. Activate a job.
2. From the ODS/Modal main menu, use the up and down arrow keys or press F9 Point
Search to go to the desired measurement point.
3. Press F7 Display Data.
If the measurement point does not have any stored data, this option is unavailable.
4. Review or modify the plots as necessary.
5. Press Enter.
8.9 Print an ODS/Modal plot to AMS Machinery
Manager
Prerequisites
• On the analyzer, press Home > ALT > F2 General Setup > F6 Set Print Mode and ensure the
default print mode is set to Send to PC.
• Ensure the same connection type is set on the analyzer and in Data Transfer.
Procedure
1.
Use the appropriate cable to connect your analyzer to a computer where AMS
Machinery Manager is installed.
2. On the computer, open Data Transfer.
3. On the analyzer, display the plot.
4. Press F7 Print Plot.
The plot appears in AMS Machinery Manager. You can print the plot as an image file
on the computer.
