6. Press F1 Start.
If the measurement direction already has data stored, the analyzer prompts you to
overwrite the data. Measurement directions with data are highlighted green. The
defined plots appear.
Note
Press F2 Next Input Response to display the data for the next response input, if you set up more
than two inputs.
7. Press the Enter key to return the ODS/Modal main menu to collect data for other
measurement points.
8.
Repeat the steps above until all points have data.
Postrequisites
When you transfer the job to AMS Machinery Manager, only measurement points with
data are transferred.
8.7.1 View all unmeasured points for the job
A red box appears around the current measurement point when more than one
measurement point is displayed in the matrix. The direction of the current measurement
point is red.
If you stored data on a point, the analyzer highlights the measurement directions points
with data.
Procedure
1.
Activate a job.
2. From the ODS/Modal main menu, press F12 Show Unmeas Points.
If a measurement point has data, the measurement point or its direction does not
appear.
3. Press F12 Show Measured Points to view only the measured points or all of the points in
the job.
8.7.2 Go to a measurement point
Use this option to skip one or more measurement points.
Procedure
1. Activate a job.
2. From the ODS/Modal main menu, do one of the following:
• Use the arrows on the keypad to select a different measurement point.
• Press F9 Point Search and enter desired measurement point, ignoring the zeroes at
the beginning of the number. For example, to select 0009XYZ, enter 9.
