8.6.6 Add a measurement point
You can add a point after you have collected data for a job.
Procedure
1.
From the ODS/Modal main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F6 Add Point.
4. Enter the total number of measurement points.
5. Press Enter.
8.6.7 Add a measurement direction
If your measurement point has fewer than three directions, you can add additional
directions. The option below appears after you collect data for a point.
Procedure
1. From the ODS/Modal main menu, press F8 Job Manager.
2. Use the up and down arrow keys to select a job.
3. Press F4 Edit This Job > F5 Add Meas Direction.
4. Use the up and down arrow keys to select the desired directions.
5. Press Enter.
Make sure you have your inputs set up properly. You may see "???" if an input needs
to be set up for that direction.
8.7 Collect ODS/Modal data
Note
If you cancel data collection, the existing data is not overwritten. After data is stored on a
measurement point, you can copy it to other measurement points using the Copy Data option.
Procedure
1.
Activate a job.
2. Ensure the job parameters are set as desired.
3. Connect the sensor to the analyzer and equipment to measure.
4. From the ODS/Modal main menu, use the up and down arrow keys to select a
measurement point.
5. Press F2 XYZ to select a measurement direction for the point.
The directions that are collected together are highlighted red.
ODS/Modal
177
