8.4.5 Delete a saved tachometer setup
1. From the ODS/Modal main menu, press ALT > F4 Tach Setup.
2.
From the Tachometer Setup screen, press F6 Save / Recall Setup.
3. Use the up and down arrow keys to select a saved setup.
4. Press F5 Delete Setup.
5. Press Enter.
8.5 Set up the plots
8.5.1 Set the plot types for stored and live data
The Plot Setup option lets you define the plots to display stored and live data.
Procedure
1. Activate a job.
2. From the ODS/Modal main menu, press ALT > F5 Plot Setup.
3. Select a plot.
The Data Plot Setup shows collected data, and the Live Plot Setup shows data during
collection.
4. Use the up and down arrow keys to select an option. The options vary based on the
number of inputs you set up.
Option Description
Plot Off Do not display a plot.
Waveform - All Display multiple waveforms.
Spectrum - All Display multiple spectrums.
Ref Waveform and All
Coherence
Display a waveform from the reference input, and coherence plots
for the other plots.
Ref Waveform and All
Cross Channel Phase
Display a waveform from the reference input, and cross channel
phase plots for the other plots.
Ref Waveform and All FRF
(Ref/Resp)
Display a waveform from the reference input, and FRF plots for the
other plots. FRF displays a spectrum representing the transfer
function of the reference input/the response input.
Ref Waveform and All FRF
(Resp/Ref)
Display a waveform from the reference input, and FRF plots for the
other plots. FRF displays a spectrum representing the transfer
function of the response input/the reference input.
Waveform - Reference Display the waveform from the reference input.
Spectrum - Reference Display the spectrum from the reference input.
Waveform - Response Display the waveform from the response input.
ODS/Modal
