8.3 Sensors and inputs
8.3.1 Set the number of inputs
After you collect data, you cannot change the number of inputs for the job. You can
modify the sensors.
Procedure
1.
From the ODS/Modal main menu, press F8 Job Manager > F4 Edit This Job > F12 Input Setup
> F1 Select Input.
Note
After you collect data, the F12 Input Setup key is no longer available.
2. Select one or more inputs.
Option Description
F2 Select/Unselect Input
A
Enable or disable data collection on input A.
F3 Select/Unselect Input
B
Enable or disable data collection on input B.
F4 Select/Unselect Input
C
Enable or disable data collection on input C.
F5 Select/Unselect Input
D
Enable or disable data collection on input D.
F8 A and B Collect input data from A and B simultaneously. If you select this
option, the inputs on the left side of the screen automatically
update.
F9 Triax Collect data from inputs A, B, and C. If you select this option, the
inputs on the left side of the screen automatically update. For the
CSI A0643TX triaxial accelerometer, the directions are relative to the
sensor:
• Input A = Z direction
• Input B = X direction
• Input C = Y direction
3. Press Enter.
The active inputs and units display at the bottom of the screen. Disabled inputs are
grayed out.
