• Use only Emerson's power supplies and chargers approved for use with the CSI 2140
and Emerson's battery packs. Using any power supplies and chargers other than
Emerson's approved power supplies and battery packs could not only void the
warranty, but will also most likely damage the analyzer or the battery pack.
• Do not change or remove the battery pack in the CSI 2140 with the power supply
connected to the analyzer. The CSI 2140 or battery pack may be damaged.
• When charging the CSI 2140 with the battery pack or the battery pack by itself,
ensure the ambient temperature where the analyzer is located is 32° F to 95° F (0° C
to 35° C).
• When operating the CSI 2140 with the battery pack, ensure the ambient
temperature where the analyzer is being used is -4° F to 122° F ( -20° C to 50° C).
WARNING!
• Use only Emerson's battery packs with the CSI 2140. Lithium-Ion batteries have very
specific charging requirements. Emerson-supplied power supplies and chargers are
designed to work with Emerson's Lithium-Ion battery pack. Using battery packs other
than Emerson's approved battery packs could not only void the warranty, but could also
be hazardous.
• Charge, remove, and replace the battery pack only in a non-hazardous area.
2.5.3 View the battery charge level
View the remaining charge level from the analyzer Home screen or from the LEDs on the
battery pack.
Procedure
Do one of the following:
• From the Home screen, view the remaining battery charge on the lower left side of the
screen.
• Press the button on the inside of the battery pack. Each LED indicates 20 percent
remaining charge.
Introduction to the analyzer
10
