2.5.1 Access the battery pack
The battery pack is located on the back of the analyzer. To access the battery, remove the
six screws that attach it to the analyzer.
Six battery pack screwsFigure 2-4:
WARNING!
Remove the battery pack only in a non-hazardous area.
2.5.2 Battery pack and power supply precautions
Understand and follow the precautions below before using the battery pack and power
supply.
• Do not use Emerson's battery packs, power supplies, and chargers with any product
other than their corresponding Emerson product.
