6.13 Review collected data
Review Data shows the most recent data, even if you did not store the data. If you opened
Analyze from a route measurement point, you can view only the data saved to the route
measurement point. If you created a job, you can view any data for any measurement,
including the most recent data that the analyzer did not save to a job.
Procedure
1.
From the Analyze main menu, press F2 Review Data.
2. Select the type of data to review.
The plot of the data appears. You can modify the plot as needed.
3. Press Back to return to the Analyze main menu.
6.14 Print an Analyze plot to AMS Machinery
Manager
Prerequisites
• Set the connection type on the analyzer and in AMS Machinery Manager.
• On the analyzer, press Home > ALT > General Setup > F6 Set Print Mode and ensure the
default print mode is Send to PC.
Procedure
1. Use the appropriate cable to connect your analyzer to a computer where AMS
Machinery Manager is installed.
2. On the computer, open Data Transfer.
3. On the analyzer, display the plot after collecting the data or from the Review Data
option.
4. Press F7 Print Plot.
The plot appears in AMS Machinery Manager. You can save the plot as an image file
and send it to a local printer or save it to your computer.
6.15 Print a plot to a memory card
You can save a plot to a memory card if you inserted a card into the analyzer. See
Section 2.10.1 for more information.
Prerequisites
On the analyzer, press Home > ALT > F2 General Setup > F6 Set Print Mode and ensure the
default print mode is set to Store as BMP on CARD or Store as JPG on CARD.
