Option Description
F10 Gain Decrease the amplitude of the audio signal. The signal gain affects the
volume. You can also use the down arrow key.
F12 Mute Mute or unmute the audio.
3. Press F4 Acquire Data (if available) to begin collecting data, or press Enter to return to
the Analyze main menu.
You can now listen to the vibration signal. The Home key is disabled while you are
listening to data.
Note
If you selected Listen To Live Data from the Analyze main menu or a plot screen, Acquire Data is
not available.
4. To stop the listening mode, press Enter or Back and go to the Comm Setup option on
the Home screen to disable the radio.
6.11 Redo a measurement
1. From Manual Analyze or an Analysis Expert, select the desired measurement.
2.
Press F8 Start or Enter.
The analyzer collects new data.
6.12 Store data to a route or a job
Unlike other programs on the analyzer, Analyze requires you to manually save the data
after a measurement completes. Other programs save data automatically.
Procedure
1. After the measurement completes and the plot displays, press F9 Store Data.
If you opened Analyze from a route point, the data is automatically saved to the
route.
2. To save the data to a job, select or add a measurement in the job on the Current Job
screen.
3. Press F8 Store Data to Meas.
The measurement is labeled with the date, time, and type of measurement.
Analyze and Advanced Analyze
140
