3. Press Start or Enter to collect the data.
4.
Press Enter to view the data.
One or more plots display after the data is collected.
5. Press F9 Store Data to save the data to a route or a job, or press F8 Start to redo the
measurement.
6.8.4 High Resolution Analysis
High Resolution Analysis increases the resolution of spectral data to separate closely-spaced
peaks and sideband frequencies for rotor bar or gear mesh problems. High Resolution Analysis
acquires data with better resolution than the standard route or marked spectra. If you
collect data on the measurement point, High Resolution Analysis increases the resolution
based on the original resolution setting.
Tip
If you mark a frequency with a cursor before running High Resolution Analysis, the increased resolution
is applied to the marked frequency. As resolution increases, the data collection time increases.
Prerequisites
• Set up the sensor.
• Attach the sensor to the analyzer and the machine.
Procedure
1.
Create a job or open Analyze from a route measurement point.
2. From the Analyze main menu, press F5 High Resolution Analysis.
3. Press Start or Enter to collect the data.
4. Press Enter to view the data.
One or more plots display after the data is collected.
5. Press F9 Store Data to save the data to a route or a job, or press F8 Start to redo the
measurement.
6.8.5 Bearing/Gear Analysis - PeakVue
Bearing/Gear Analysis - PeakVue detects anti-friction bearing or gear defects earlier than
normal vibration measurements. It also detects bearing defects on extremely slow turning
shafts that do not generate enough vibration to detect with normal measurements. See
Section 6.7.5 for more information on PeakVue technology measurements.
If you collected data on the measurement point, Bearing/Gear Analysis - PeakVue starts with
the original acquisition settings and adds the PeakVue processing. You can also set a lower
Fmax for the PeakVue measurement if the original spectrum shows no vibration peaks past
Analyze and Advanced Analyze
