Data Collection
Note
For best results, collect data and mark a frequency in the spectrum before you run an Analysis Expert.
The Analysis Expert performs a customized acquisition based on the marked frequency and other point
setup information. You are not required to mark a frequency before running an Analysis Expert.
To collect data using an Analysis Expert:
1.
Open Analyze from a route or create a job.
2. Select an Analysis Expert from the Analyze main menu.
3. Press Enter to collect the data.
4. Review the plot of the collected data.
5. Store the data.
6.8.1 Recommended uses of Analysis Experts
Uses for Analysis ExpertsTable 6-1:
Symptom or task Recommended Analyze Expert
You see unknown frequencies are
below the running speed.
• High Resolution Analysis. See Section 6.8.4.
• Low Frequency Analysis. See Section 6.8.6.
You suspect looseness. • High Resolution Analysis with 2x turning speed peak marked.
See Section 6.8.4.
• Synchronous Analysis. See Section 6.8.16.
You want to distinguish between
imbalance and resonance.
• Bump Test Equipment Running. See Section 6.8.11.
• Bump Test Equipment Off. See Section 6.8.10.
• High Resolution Analysis with 1x turning speed peak marked
with a cursor. See Section 6.8.4.
You want to confirm if vibration is
bearing-related (non synchronous).
• Synchronous Analysis. See Section 6.8.16.
• High Frequency Analysis. See Section 6.8.3.
You suspect resonance. • Bump Test Equipment Running. See Section 6.8.11.
• Bump Test Equipment Off. See Section 6.8.10.
• Coast Down Peak Hold with no tachometer signal. See
Section 6.8.12.
• Coast Down Peak and Phase with tachometer signal. See
Section 6.8.13.
You suspect an electrical problem. • High Resolution Analysis with 2x turning speed peak marked
with a cursor. See Section 6.8.4.
• High Resolution Analysis with 1x turning speed peak marked
with a cursor. See Section 6.8.4.
• Rotor Bar Test Motor Current. See Section 6.8.14.
You suspect a rolling element
bearing failure.
• Bearing Gear Analysis - PeakVue. See Section 6.8.5.
• High Frequency Analysis. See Section 6.8.3.
Analyze and Advanced Analyze
106
