PeakVue Prefilters
Band-pass 20-150 Hz High-pass 2 kHz
Band-pass 50-300 Hz High-pass 5 kHz
Band-pass 100-600 Hz Band-pass 5-6.5 kHz
Band-pass 500-1 kHz High-pass 10 kHz
High-pass 500 Hz High-pass 20 kHz
High-pass 1 kHz
Demodulation
Demodulation uses a user-specified band-pass or high-pass filter to remove all low-
frequency components in the signal. The signal is amplified and amplitude demodulated,
which creates a low-frequency signal consisting of the envelope of the original signal. The
amplitude of the original signal is not maintained when demodulation is used.
Demodulation frequency ranges
The maximum frequency using the built-in demodulator is 10 kHz. The analyzer adjusts
any entered frequency to the next highest predefined frequency value.
Frequency ranges
20 Hz 200 Hz 1 kHz
50 Hz 400 Hz 2 kHz
100 Hz 500 Hz 5 kHz
6.7.6 Triggers
Triggers start the collection of each average based on particular events. Four trigger
options are available.
Note
When you collect Cascade data, the Level trigger is used only to start collecting the first spectrum in
the series. All other spectra are collected without a trigger. These two modes do not permit pre-
triggering.
Option Description
Trigger Off Collect data when you press Enter on the analyzer.
