5. Press Enter.
6.6.4 Rename a saved tachometer setup
1. From the Analyze main menu, press F1 Manual Analyze > F7 Tach Setup.
2.
From the Tachometer Setup screen, press F6 Save / Recall Setup.
3. Use the up and down arrow keys to select a saved setup.
4. Press F4 Edit Setup Desc.
5. Enter up to 27 characters for the name.
6. Press Enter.
6.6.5 Delete a saved tachometer setup
1. From the Analyze main menu, press F1 Manual Analyze > F7 Tach Setup.
2. From the Tachometer Setup screen, press F6 Save / Recall Setup.
3. Use the up and down arrow keys to select a saved setup.
4. Press F5 Delete Setup.
5. Press Enter.
6.7 Common data collection parameters
This section describes parameters that are available in most of the Analysis Experts and
Manual Analyze. To view these options, open Manual Analyze for a measurement.
6.7.1 Fmax and Fmin
The Fmax and Fmin values set the maximum and minimum frequency limits for your
measurements. Equipment with high operating speeds requires a higher Fmax to capture
all crucial information. The Fmin (low cutoff) removes very low frequency integration noise
from the overall measurement and is normally set at 2 Hz. You can set Fmin to 0, but the
minimum value is the second line in the spectrum, where the Fmin value is equal to 2x line
resolution.
Measurement Recommended setting
Fingered elements such as gear teeth, fan
blades, pump vanes, and bearing elements
(3 x the number of fingers) x the operating
speed
Non-fingered elements 10 x the operating speed
Coast up, coast down recordings 200 to 400 Hz (12,000-24,000 cpm)
