2. Press F3 Edit This Job > F1 Route Equip.
3.
Use the up and down arrow keys to select a route, and press F4 Select.
4. Use the up and down arrow keys to select the route equipment, and press F4 Select.
6.3 Set display parameters
6.3.1 Set the overlap
Overlap controls how much each new average overlaps the previous average when taking
a spectra measurement. The higher the overlap percentage, the less newly acquired data is
needed to generate a spectrum. A higher percentage decreases the data collection time.
The default overlap, 67 percent, is acceptable for most situations.
Procedure
1. From the Analyze main menu, press ALT > F4 Set Overlap.
2. Enter a percent between 0 and 99.
The default is 67 percent.
3. Press Enter.
6.3.2 Select the data to display when collecting a spectrum
You can select the type of information that displays on the screen while you collect data.
Note
This option is available for only the Spectra mode in Manual Analyze.
Procedure
1.
From the Analyze main menu, press ALT > F5 Live Display Setup.
2. Use the up and down arrow keys to select an option.
Option Description
Status Display the inputs and number of averages. The default is Status.
Waveform Display the data as a waveform.
Spectrum Display the data as a spectrum.
Dual Display the data as a waveform and a spectrum.
3. Press Enter.
Analyze and Advanced Analyze
94
