Instruction Manual

HDMI Audio Splitter/De-embedder
Introduction
CP-HDA2 is a high-quality HDMI audio splitter/de-embedder, with 1 HDMI and 1 split stereo audio
output, HDCP compliant and HDTV compatible.
The antistatic case design of CP-HDA2 provides good protection for stable performance, and its
transmission resolution ups to 1920*1200@60Hz.
1. Features
 De-embed and split the HDMI audio to two different formats output.
 Built-in HDCP internal management, HDMI 1.3.
 HDTV compatible with High Definition Transmission up to 1920*1200@60Hz resolution (max).
 Bandwidth: 340 MHz (10.2 Gbit/s).
 Wall/table-mountable aluminium enclosure, PT case design.
 Antistatic case design: providing good protection for long-term and stable performance
2. Specification
Video Input Video Output
Input 1 HDMI Output
1 HDMI
1 Stereo Audio
Input Connector HDMI 1.3 Output Connector
HDMI 1.3
3.5mm jack
Input Level T.M.D.S. 2.9V/3.3V Output Level T.M.D.S. 2.9V/3.3V
Input Impedence 50Ω Output Impedence 50Ω
Video General
Gain 0 dB Bandwidth 340 MHz (10.2 Gbit/s)
Video Signal HDMI 1.3 Maximum Pixel Clock 165MHz
Resolution Range
Up to 1920 x 1200 or
1080P@60Hz
Delay Time 5nS (±1nS)
Consumer
Electronics
Control (CEC)
Supports CEC wired infrared data pass-through using the HDMI 1.3 standard
HDCP
Management
Compliant with High-bandwidth Digital Content Protection (HDCP) using DVI and
HDMI 1.3 standards.
Audio General
Frequency
Response
20Hz ~ 20KHz CMRR >70dB@20Hz~20KHz
SNR >80dB Bandwidth 20Hz ~ 25KHz
Stereo Channel
Separation
>75dB@20Hz ~ 20KHz THD + Noise
1%@1KHz,
0.3%@20KHz
General
Power Supply 100VAC ~ 240VAC, 50/60Hz Power Consumption 3W
Temperature
-20 ~ +70℃
Humidity 10% ~ 90%
Case Dimension W52.5 x L92 x H28 mm Product Weight 0.2Kg
