User's Manual

Related Products
802.11ac 5GHz miniPCIe
Gigabit Power over Ethernet
WLE900VX
WLE600V5-23
WLE900V5-23
POE2408
- Output Voltage: 24VDC
- Max Output Watts: 19W
Optional configuration
USB Extension
(USB HUB BOARD-1.00-ST)
USB board
External board:
can support 3 x USB 2.0 ports and
1 x miniPCIe-based USB 2.0 only interface
(e.g. 3G modems)
PSE pass-thru module
(P-PSE-M-6A03-SPL)
PSE pass-thru module: Optional module to
allow power to pass through the 2nd Ethernet
port to an IEEE 802.3af/at compatible device,
such as a surveillance camera
Model
Extended applications
USB signal
USB External board
(USB HUB BOARD-1.00-ST)
802.3af PoE pass-thru
802.3af
PoE power supply
WPJ344
Support 1× USB 2.0 port
support 3 x USB 2.0 ports
and
1 x miniPCIe-based USB
2.0 only interface
Optional
(PSE pass-thru module)
support
WPJ558
Support 1× USB 2.0 port
or
PCIe slot Support Third
Party 3G/LTE Module
support 3 x USB 2.0 ports
and
1 x miniPCIe-based USB
2.0 only interface
support
WPJ342
Support 1× USB 2.0 port
or
PCIe slot Support Third
Party 3G/LTE Module
Optional
(802.3af module)
WPJ531
Support 1× USB 2.0 port
or
PCIe slot Support Third
Party 3G/LTE Module
Optional
(802.3af module)
WP546
Support 2× USB 2.0 port
Optional
(PSE pass-thru module)
support
WP543
Support 2× USB 2.0 port
support
Compex embedded board extended applications list
