User's Manual

Technical Specifications
System Information
Processor
Qualcomm-Atheros AR9344 MIPS 74Kc
System Memory
128MB(64*2) DDR2
NOR Flash
8MB (max 16MB optional)
1
MiniPCI Slot
1 x 9.2mm MiniPCIe slot
Ethernet
2 Gigabit ports with Auto-MDI/X
Extras
Serial Port
2
, JTAG
3
, Reset Button, Surge Arrestor, Watchdog Timer
Power Solutions
High voltage
DC Jack Input:24-48V, Passive PoE: 24-48V, IEEE 802.3af/at PoE
Standard 802.3af PoE input:(Optional)
4
Low voltage
DC Jack Input: 9-24V, Passive PoE: 12-24V
Power Consumption
7W
RoHS Compliance
Yes
Humidity
Operating: 5% to 95% (non-condensing)
Storage: Max.90% (non-condensing)
Temperature Range
Operating:-20ºC to 70ºC
Storage: -40ºC to 90ºC
Dimension
117 x 105 x 17 (mm)
2.4GHz
On-board Radio
Transmit
Power
Data Rate
Aggregate Power
1M
25dBm
11M
23dBm
6M
25dBm
54M
22dBm
HT20 MCS0
25dBm
HT20 MCS7
22dBm
HT40 MCS0
25dBm
HT40 MCS7
22dBm
Receiver
Sensitivity
Data Rate
6M
-90dBm
54M
-75dBm
HT20 MCS0
-90dBm
HT20 MCS7
-72dBm
HT40 MCS0
-88dBm
HT40 MCS7
-70dBm
Max of concurrent
associations
Encryption
Client
Latency
TCP
[each client upload and download
randomly from 384Kbps to 768Kbps]
UDP
[each client upload
and download 2Mbps]
WPA2-PSK
<100ms
Single radio
Dual radio
Single radio
Dual radio
40 clients
70clients
(35 per radio)
20 clients
30clients
(15 per radio)
1 Depends on Order Configurations
2 Serial Port is a 4-pin header (TTL) + Serial Converter is available to change the TTL signals on board to RS232 signals
for debugging.Configurations are subjec to change without notification
3 JTAG Port is a 14-pin header + JTAG kit is for writing your own developed loader and firmware directly
4 In this mode, it can be powered from 802.3af/3at PoE switches and PoE injectors. It is able to return a PD classification
of 0. The DC jack can accept a voltage range of 24V to 56V but the PoE input needs a minimum voltage of 36V
