User's Manual

MCS0 -95/ -91dBm ± 2dB MCS0 -96/ -92dBm ± 2dB
MCS1 -94/ -90dBm ± 2dB MCS1 -95/ -91dBm ± 2dB
MCS2 -92/ -88dBm ± 2dB MCS2 -93/ -89dBm ± 2dB
MCS3 -88/ -84dBm ± 2dB MCS3 -90/ -86dBm ± 2dB
MCS4 -85/ -81dBm ± 2dB MCS4 -87/ -81dBm ± 2dB
MCS5 -81/ -77dBm ± 2dB MCS5 -83/ -76dBm ± 2dB
MCS6 -80/ -76dBm ± 2dB MCS6 -81/ -76dBm ± 2dB
MCS7 -77/ -73dBm ± 2dB MCS7 -79/ -73dBm ± 2dB
MCS8 -94/ -90dBm ± 2dB MCS8 -95/ -91dBm ± 2dB
MCS9 -92/ -87dBm ± 2dB MCS9 -93/ -89dBm ± 2dB
MCS10 -89/ -85dBm ± 2dB MCS10 -90/ -86dBm ± 2dB
MCS11 -86/ -82dBm ± 2dB MCS11 -87/ -83dBm ± 2dB
MCS12 -83/ -79dBm ± 2dB MCS12 -84/ -80dBm ± 2dB
MCS13 -78/ -74dBm ± 2dB MCS13 -79/ -75dBm ± 2dB
MCS14 -77/ -73dBm ± 2dB MCS14 -77/ -73dBm ± 2dB
802.11
a/ n
HT20
MCS15 -74/ -69dBm ± 2dB
802.11
b/ g/ n
HT20
MCS15 -75/ -71dBm ± 2dB
MCS0 -91/ -87dBm ± 2dB MCS0 -90/ -86dBm ± 2dB
MCS1 -90/ -86dBm ± 2dB MCS1 -90/ -86dBm ± 2dB
MCS2 -88/ -84dBm ± 2dB MCS2 -89/ -85dBm ± 2dB
MCS3 -85/ -81dBm ± 2dB MCS3 -87/ -82dBm ± 2dB
MCS4 -82/ -78dBm ± 2dB MCS4 -84/ -79dBm ± 2dB
MCS5 -78/ -74dBm ± 2dB MCS5 -79/ -75dBm ± 2dB
MCS6 -77/ -73dBm ± 2dB MCS6 -78/ -74dBm ± 2dB
MCS7 -74/ -70dBm ± 2dB MCS7 -75/ -71dBm ± 2dB
MCS8 -91/ -87dBm ± 2dB MCS8 -90/ -86dBm ± 2dB
MCS9 -88/ -84dBm ± 2dB MCS9 -89/ -85dBm ± 2dB
MCS10 -86/ -82dBm ± 2dB MCS10 -87/ -83dBm ± 2dB
MCS11 -83/ -79dBm ± 2dB MCS11 -84/ -80dBm ± 2dB
MCS12 -80/ -76dBm ± 2dB MCS12 -81/ -77dBm ± 2dB
MCS13 -75/ -71dBm ± 2dB MCS13 -76/ -72dBm ± 2dB
MCS14 -73/ -69dBm ± 2dB MCS14 -74/ -68dBm ± 2dB
802.11
a/ n
HT40
MCS15 -70/ -66dBm ± 2dB
802.11
b/ g/ n
HT40
MCS15 -71/ -67dBm ± 2dB
DRI VER I NFORMATI ON
Driver Linux Madwifi, WindowsXP , Windows 2000,Windwos Vista
c
Configurations are subjected to change without notice
