Technical Specifications
Chipset
AR9220
Host I nterface
PCI I nterface v2.3 (Type I I I -B Mini PCI form factor)
Operating
Voltage
3.3 VDC
Pow er
Consumption
2.4W
Antenna
Connector
2 x U.FL Antenna Connector
I EEE 802.11a : 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps 9Mbps 6Mbps
IEEE 802.11b : 11Mbps 5.5Mbps 2Mbps 1Mbps
54Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps 9Mbps 6Mbps
automatically
IEEE 802.11g :
Fallback to 5.5Mbps, 2Mbps, 1Mbps
1Nss: 65Mbps @ 800GI , 72.2Mbps @ 400GI (Max.) 20MHZ
2Nss: 130Mbps @ 800GI, 144.4Mbps @ 400GI (Max.)
1Nss: 135Mbps @ 800GI, 150Mbps @ 400GI (Max.)
Data Rate
IEEE 802.11n :
40MHz
2Nss: 270Mbps @ 800GI, 300Mbps @ 400GI (Max.)
Modulation
Techniques
OFMD: BPSK, QPSK, 16 QAM, 64QAM
DSSS: DBPSK, DQPSK, CCK
Security
64/ 128-bit WEP, TKIP, AES, I EEE802.1x authentication
Certificate
FCC, CE
ROHS
Compliance
Yes
Environment
Specifications
Operating: -20º C to 70º C
Storage: -65º C to 100º
Humidity
5% to 95% (non-condensing)
Dimension
59.6 x 51 x 3 mm
WLM200NX MI MO MI NI PCI CARD RADI O
TX SPECI FI CATI ONS TX SPECI FI CATI ONS
DataRate TX Power Tolerance DataRate TX Power Tolerance
6-24Mbps 18dBm ± 2dB 1Mbps 20dBm
±2dB
36Mbps 18dBm ± 2dB 2Mbps 20dBm
±2dB
48Mbps 17dBm ± 2dB 5.5Mbps 20dBm
±2dB
802.11a
54Mbps 16dBm ± 2dB
802.11b
11Mbps 20dBm
±2dB
6-24Mbps 20dBm ± 2dB
HT20 @800GI(400GI): + 16 ~ + 20dBm
36Mbps 19.5dBm ± 2dB
2.4GHz
HT40 @800GI(400GI): + 14 ~ + 18dBm
48Mbps 18.5dBm ± 2dB 5GHz
HT20 @800GI(400GI): + 10 ~ + 18dBm
802.11g
54Mbps 17dBm ± 2dB
802.11n
RX SPECI FI CATI ONS
（802.11b）
Data Rate Sensitivity (Typical/ Maximum 2Rx) Tolerance
1M -96/ -92Bm ± 2dB
5.5M -94/ -90dBm ± 2dB
802.11b
11M -91/ -87dBm ± 2dB
RX SPECI FI CATI ONS(802.11a)
RX SPECI FI CATI ONS（802.11g）
Data Rate Sensitivity
( Typical/ Maximum 2Rx)
Tolerance Data Rate Sensitivity
( Typical/ Maximum 2Rx)
Tolerance
6M -95/ -91dBm ± 2dB 6M -96/ -92dBm ± 2dB
9M -95/ -91dBm ± 2dB 9M -96/ -92dBm ± 2dB
12M -95/ -91dBm ± 2dB 12M -96/ -92dBm ± 2dB
18M -94/ -90dBm ± 2dB 18M -95/ -91dBm ± 2dB
24M -90/ -86dBm ± 2dB 24M -92/ -88dBm ± 2dB
36M -87/ -83dBm ± 2dB 36M -89/ -85dBm ± 2dB
48M -83/ -79dBm ± 2dB 48M -85/ -81dBm ± 2dB
802.11a
54M -82/ -78dBm ± 2dB
802.11g
54M -83/ -79dBm ± 2dB
