WLM 200N2 MI MO MI NI PCI CARD RADI O OPERATI NG FREQUENCE 2.412- 2.484GHz
TX SPECI FI CATI ONS TX SPECI FI CATI ONS
DataRate TX Power Tolerance DataRate TX Power Tolerance
11Mbps 26dBm ± 2dB 6-24Mbps 26dBm ± 2dB
5.5Mbps 26dBm ± 2dB 36Mbps 26dBm ± 2dB
2Mbps 26dBm ± 2dB 48Mbps 22dBm ± 2dB
802.11b
1Mbps 26dBm ± 2dB
802.11g
54Mbps 21dBm ± 2dB
MCS 0 23dBm ± 2dB MCS 0 22dBm ± 2dB
MCS 1 23dBm ± 2dB MCS 1 22dBm ± 2dB
MCS 2 23dBm ± 2dB MCS 2 22dBm ± 2dB
MCS 3 23dBm ± 2dB MCS 3 22dBm ± 2dB
MCS 4 23dBm ± 2dB MCS 4 22dBm ± 2dB
MCS 5 22dBm ± 2dB MCS 5 22dBm ± 2dB
MCS 6 21dBm ± 2dB MCS 6 21dBm ± 2dB
MCS 7 20dBm ± 2dB MCS 7 20dBm ± 2dB
MCS 8 23dBm ± 2dB MCS 8 22dBm ± 2dB
MCS 9 23dBm ± 2dB MCS 9 22dBm ± 2dB
MCS 10 23dBm ± 2dB MCS 10 22dBm ± 2dB
MCS 11 23dBm ± 2dB MCS 11 22dBm ± 2dB
MCS 12 23dBm ± 2dB MCS 12 22dBm ± 2dB
MCS 13 22dBm ± 2dB MCS 13 22dBm ± 2dB
MCS 14 21dBm ± 2dB MCS 14 21dBm ± 2dB
2.4Ghz
11n
HT20
MCS 15 20dBm ± 2dB
2.4Ghz
11n
HT40
MCS 15 20dBm ± 2dB
RX SPECI FI CATI ONS RX SPECI FI CATI ONS
DataRate
Sensitivity
（Maximum/ Typical 2Rx）
Tolerance
DataRate Sensitivity
（Maximum/ Typical 2Rx）
Tolerance
6 Mbps -96/ -92dBm ± 2dB 1 Mbps -96/ -92dBm ± 2dB
9 Mbps -96/ -92dBm ± 2dB 5.5Mbps 94/ -90dBm ± 2dB
12 Mbps -96/ -92dBm ± 2dB 11 Mbps -91/ -87dBm ± 2dB
18 Mbps -95/ -91dBm ± 2dB
24Mbps -92/ -88dBm ± 2dB
38Mbps -89/ -85dBm ± 2dB
48Mbps -85/ -81dBm ± 2dB
802.11g
54Mbps -83/ -79dBm ± 2dB
802.11b
MCS0 -96/ -92dBm ± 2dB MCS0 -90/ -86dBm ± 2dB
MCS1 -95/ -91dBm ± 2dB MCS1 -90/ -86dBm ± 2dB
MCS2 -93/ -89dBm ± 2dB MCS2 -89/ -85dBm ± 2dB
MCS3 -90/ -86dBm ± 2dB MCS3 -87/ -82dBm ± 2dB
MCS4 -87/ -81dBm ± 2dB MCS4 -84/ -79dBm ± 2dB
MCS5 -83/ -76dBm ± 2dB MCS5 -79/ -75dBm ± 2dB
MCS6 -81/ -76dBm ± 2dB MCS6 -78/ -74dBm ± 2dB
MCS7 -79/ -73dBm ± 2dB MCS7 -75/ -71dBm ± 2dB
MCS8 -95/ -91dBm ± 2dB MCS8 -90/ -86dBm ± 2dB
MCS9 -93/ -89dBm ± 2dB MCS9 -89/ -85dBm ± 2dB
MCS10 -90/ -86dBm ± 2dB MCS10 -87/ -83dBm ± 2dB
MCS11 -87/ -83dBm ± 2dB MCS11 -84/ -80dBm ± 2dB
MCS12 -84/ -80dBm ± 2dB MCS12 -81/ -77dBm ± 2dB
MCS13 -79/ -75dBm ± 2dB MCS13 -76/ -72dBm ± 2dB
MCS14 -77/ -73dBm ± 2dB MCS14 -74/ -68dBm ± 2dB
802.11
b/ g/ n H20
MCS15 -75/ -71dBm ± 2dB
802.11
b/ g/ n H40
MCS15 -71/ -67dBm ± 2dB
