Operation and Management
60 Modular SAN Array 1000 User Guide
Table 11 defines the illuminations of the Link Status Indicators 2 and 3.
Table 11: Fibre Channel I/O Module Link Status Indicators
1-Gb Indicator
1
2-Gb Indicator
2
Description
Off Off A link has not been established since the
application of power, initiation of reset,
hot-plug of Fibre I/O module, the
removal of transceiver or the hot-plug of
the transceiver.
Green Off A 1-Gb link is active and the status is
good.
Flashing Amber Off A 1-Gb link was established but is now
inactive.
Off Green A 2-Gb link is active and the status is
good.
Off Flashing Amber A 2-Gb link was established but is now
inactive.
Flashing Amber Flashing Amber The controller was removed or there is
no Fibre Card installed.
