Controller Display Messages
225Modular SAN Array 1000 User Guide
510 INITIALIZING
FIBRE SUBSYSTEM
Informational The array controller’s fibre
subsystem is being
initialized as part of the
power up sequence.
513 UNCORRECTED
ECC MEMORY ERROR
SEEN
Error The array controller has
detected an uncorrectable
error in the ECC memory
on the memory cache
board.
Remove the failed array
controller and replace the
memory cache board with
a new one.
514 FIBRE SWITCH
HARDWARE FAILURE
Error The MSA SAN Switch 2/8
that is installed in the
MSA1000 failed to
establish a connection with
the array controller over
fibre channel.
Remove the MSA Fabric
Switch 6 switch, wait one
minute and then reinsert it
insuring it is fully seated in
the chassis. Wait one
minute and check the LCD
to see if a new copy of this
error message is created.
The service indicator LED
on the back of the switch
should turn solid green if
the switch is operating
normally. The service
indicator LED will flash
amber if it has failed
again.
Should the issue persist
please contact HP support.
Table 20: LCD Message Descriptions
Message Type Description Action
