169Modular SAN Array 1000 User Guide
C
Specifications
This appendix provides operating and physical specifications for the MSA1000.
Table 17: MSA1000 Specifications
Parameter English Metric
Dimensions
Height
Depth
Width
6.9 in
20.5 in
19.0 in
17.5 cm
52.1 cm
48.3 cm
Weight
No drives installed,
single power supply
50 lb 22.7 kg
Input Power Requirements
Rated Input Voltage
Rated Input Frequency
Rated Input Current
Input Power (max)
100 to 240 VAC
50 - 60 Hz
7.35 A M a x
641 W*
100 to 240 VAC
50 - 60 Hz
7.35 A M a x
641 W*
Heat Dissipation (max) 2187 Btu/hr* 2187 Btu/hr*
Temperature Range
Operating
Shipping
50° to 95° F
-22° to 122° F
10° to 35° C (derated
1°C per 1000 feet of
elevation to 10000
ft.)
-30° to 50° C
Relative Humidity
(non-condensing)
Operating
Non-operating
10% to 90%
up to 95%
10% to 90%
up to 95%
