Command Line Interface (CLI)
135Modular SAN Array 1000 User Guide
SYSTEM_NAME=”XXX”—the system name, where XXX represents any user
defined phrase, up to 20 alphanumeric characters.
READ_CACHE=50—the read cache. This value must be between 0 and 100.
WRITE_CACHE=50—the write cache. This value must be between 0 and 100.
Note: Read_cache plus write_cache must equal 100.
Example CLI Response
Global Parameters:
System Name:XXX
Rebuild Priority:HIGH
Expand Priority:HIGH
Total Cache:128MB
50% Read Cache:64MB
50% Write Cache:64MB
Setting the Controller ID
To assign a unique name to each controller installed in the MSA1000:
Basic Command
SET THIS_CONTROLLER_ID
SET OTHER_CONTROLLER_ID
Example Command
CLI> SET THIS_CONTROLLER_ID 123
Command Options
123—the user-defined ID for the controller. The ID can be up to 230
alphanumeric characters or a decimal number in the range of 0 though 65535.
In this example, the controller ID will be changed to 123.
Example CLI Response
CLI> SET THIS_CONTROLLER_ID 123
Controller identifier 123 created.
Note: To verify the controller ID assignment, use the SHOW THIS_CONTROLLER or
SHOW OTHER_CONTROLLER commands.
