Array Configuration Utility (ACU)
113Modular SAN Array 1000 User Guide
Table 15: Possible Tasks in Standard Configuration Mode
Item Available Task
Controller Clear Configuration
Controller Settings
Create Array
Logical Drive Array Accelerator Settings
Selective Storage Presentation (for MSA1000 and
Smart Array Cluster Storage controllers)
More Information
Array Assign Spare
Create Logical Drive
Delete
Expand
Remove Spare
More Information
Logical Drive Delete
Extend Size
Migrate RAID / Stripe Size
Selective Storage Presentation (for RA4x00
controllers)
More Information
Unused space No available tasks are associated with this item.
Note: The More Information task is present for all items except unused space. When
you click this task link, a popup window is displayed with additional information
about the selected item.
230941-005_MSA1000_UG.book Page 113 Thursday, April 17, 2003 5:53 PM
