Spare part
number
Description
536537-211 Keyboard for use in Hungary on computers with 15-in displays
536537-221 Keyboard for use in the Czech Republic on computers with 15-in displays
536537-231 Keyboard for use in Slovakia on computers with 15-in displays
536537-251 Keyboard for use in Russia on computers with 15-in displays
536537-261 Keyboard for use in Bulgaria on computers with 15-in displays
536537-281 Keyboard for use in Thailand on computers with 15-in displays
536537-291 Keyboard for use in Japan on computers with 15-in displays
536537-A41 Keyboard for use in Europe on computers with 15-in displays
536537-AB1 Keyboard for use in Taiwan on computers with 15-in displays
536537-AD1 Keyboard for use in South Korea on computers with 15-in displays
536537-B31 Keyboard for International use on computers with 15-in displays
536537-B71 Keyboard for use in Finland on computers with 15-in displays
536537-BA1 Keyboard for use in Slovenia on computers with 15-in displays
536537-BB1 Keyboard for use in Israel on computers with 15-in displays
536537-BG1 Keyboard for use in Switzerland on computers with 15-in displays
536537-DD1 Keyboard for use in Iceland on computers with 15-in displays
536537-DJ1 Keyboard for use in Greece on computers with 15-in displays
536538-001 Cable Kit for use in computers with 14-in displays
536539-001 Cable Kit for use in computers with 15-in displays
536598-001 Speakers for use in computers with 15-in displays
536599-001 SIM
537921-001 HP Integrated Bluetooth 2.1 module
538971-001 160-GB, 7200-rpm hard drive (includes hard drive bracket)
538972-001 160-GB, 7200-rpm hard drive (includes hard drive bracket)
572032-001 6-cell, 47-Wh Li-ion battery for use in computers with 14-in displays
572520-001 Intel Wi-Fi Link 1000, 802.11b/g/n WLAN module for use in Andorra, Antigua and Barbuda, Argentina, Aruba,
Australia, Austria, Azerbaijan, the Bahamas, Barbados, Belgium, Bolivia, Bosnia and Herzegovina, Brazil,
Brunei, Bulgaria, Canada, Cayman Islands, Chile, China, Colombia, Costa Rica, Croatia, Cyprus, the Czech
Republic, Denmark, the Dominican Republic, Ecuador, Egypt, El Salvador, Estonia, Finland, France, French
Guiana, Guadeloupe, Guam, Georgia, Germany, Ghana, Greece, Guatemala, Haiti, Honduras, Hong Kong,
Hungary, Iceland, India, Indonesia, Ireland, Israel, Italy, Ivory Coast, Jamaica, Japan, Jordan, Kenya, Kuwait,
Kyrgyzstan, Latvia, Lebanon, Liechtenstein, Lithuania, Luxembourg, Malawi, Malaysia, Malta, Martinique,
Mauritius, Mexico, Monaco, Montenegro, Morocco, the Nether Antilles, the Netherlands, New Zealand,
Nicaragua, Nigeria, Nigeria, Oman, Pakistan, Panama, Paraguay, Peru, the Philippines, Poland, Portugal,
Puerto Rico, Quatar, Romania, San Marino, Saudi Arabia, Senegal, Singapore, Slovakia, Slovenia, South
Africa, South Korea, Spain, Sri Lanka, Sweden, Switzerland, Taiwan, Tanzania, Thailand, Trinidad and
Tobago, Turkey, United Arab Emirates, the United Kingdom, the United States, Uruguay, the U.S. Virgin
Islands, Venezuela, and Vietnam
572709-001 14.0-in WXGA HD AntiGlare display assembly for use in red computers
Sequential part number listing 53
