I/O address (hex) System function (shipping configuration)
7020 - 703F Intel ICH9 Family USB Universal Host Controller – 2936
7040 - 705F Intel ICH9 Family USB Universal Host Controller – 2935
7060 - 707F Intel ICH9 Family USB Universal Host Controller – 2934
7080 - 709F Intel ICH9 Family USB Universal Host Controller – 2939
70A0 - 70BF Intel ICH9 Family USB Universal Host Controller – 2938
70C0 - 70DF Intel ICH9 Family USB Universal Host Controller – 2937
70E0 - 70E7 ICH9M-E/M SATA AHCI Controller
70E8 - 70EF ICH9M-E/M SATA AHCI Controller
70F0 - 70F7 Mobile Intel 4 Series Express Chipset Family
70F8 - 70FB ICH9M-E/M SATA AHCI Controller
70FC - 70FF ICH9M-E/M SATA AHCI Controller
EF80 - EF9F Motherboard resources
FE00 - FE0F Motherboard resources
FE80 - FE8F Motherboard resources
FFFF - FFFF Motherboard resources
System memory map specifications, Windows Vista
Memory address System function
000A0000-000BFFFF Mobile Intel 4 Series Express Chipset Family
000A0000-000BFFFF PCI Bus
80000000-8FFFFFFF Mobile Intel 4 Series Express Chipset Family
80000000-DFFFFFFF PCI Bus
90000000-903FFFFF Mobile Intel 4 Series Express Chipset Family
90400000-904FFFFF Mobile Intel 4 Series Express Chipset Family
90500000-905FFFFF Intel 82801 PCI Bridge – 2448
90600000-90603FFF Marvell Yukon 88E8072 PCI-E Gigabit Ethernet
Controller
90600000-906FFFFF Intel ICH9 Family PCI Express Port 6 – 294A
90700000-946FFFFF Intel ICH9 Family PCI Express Port 5 – 2948
94700000-986FFFFF Intel ICH9 Family PCI Express Port 3 – 2944
98700000-98703FFF Broadcom 802.11b/g WLAN
98700000-987FFFFF Intel ICH9 Family PCI Express Port 2– 2942
98800000-988FFFFF Intel ICH9 Family PCI Express Port 1 – 2940
98900000-98903FFF High Definition Audio Controller
142 Chapter 6 Specifications
