I/O address (hex) System function (shipping configuration)
7108 - 710F Standard Dual Channel PCI IDE Controller
7120 - 7127 Mobile Intel 4 Series Express Chipset Family
7128 - 712B Standard Dual Channel PCI IDE Controller
712C - 712F Standard Dual Channel PCI IDE Controller
EF80 - EF9F Motherboard resources
FE00 - FE0F Motherboard resources
FE80 - FE8F Motherboard resources
FFFF - FFFF Motherboard resources
System I/O address specifications, Windows XP
I/O address (hex) System function (shipping configuration)
000 - 01F Direct memory access controller
000 - CF7 PCI bus
020 - 021 Programmable interrupt controller
024 - 025 Programmable interrupt controller
028 - 029 Programmable interrupt controller
02C - 02D Programmable interrupt controller
02E - 02F Motherboard resources
030 - 031 Programmable interrupt controller
034 - 035 Programmable interrupt controller
038 - 039 Programmable interrupt controller
03C - 03D Programmable interrupt controller
040 - 043 System timer
04E - 04F Motherboard resources
050 - 053 System timer
060 - 060 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard with HP QLB
061 - 061 Motherboard resources
062 - 062 Microsoft ACPI-Compliant Embedded Controller
063 - 063 Motherboard resources
064 - 064 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard with HP QLB
065 - 065 Motherboard resources
066 - 066 Microsoft ACPI-Compliant Embedded Controller
067 - 067 Motherboard resources
