System Configuration menu
NOTE: Some of the listed System Configuration options may not be supported by your computer.
Select To do this
Language Change the Computer Setup language.
Boot Options
●
Set a Startup Menu delay (in seconds).
●
Enable/disable Custom Logo (disabled by default).
●
Enable/disable Display Diagnostic URL (enabled by
default).
●
Enable/disable CD-ROM boot (enabled by default).
●
Enable/disable SD Card boot (enabled by default).
●
Enable/disable floppy boot (enabled by default).
●
Enable/disable PXE Internal NIC boot (disabled by
default).
●
Set the Express Boot Popup delay in seconds.
●
Set the boot order.
Device Configurations
●
Enable/disable USB legacy support (enabled by default).
When enabled, USB legacy support allows the
following:
◦
Use of a USB keyboard in Computer Setup even
when a Windows® operating system is not running.
◦
Startup from bootable USB devices, including a hard
drive, diskette drive, or optical drive connected by a
USB port to the computer.
●
Enable/disable fan always on while connected to an AC
outlet (disabled by default).
●
Enable/disable Data Execution Prevention (select models
only; disabled by default). When enabled, the processor
can disable some virus code execution, which helps to
improve computer security.
●
SATA (Serial Advanced Technology Attachment) device
mode. The following options are available:
◦
AHCI (Advanced Host Controller Interface)
◦
IDE (Integrated Drive Electronics)
NOTE: Availability of the options above varies by
computer model.
●
Enable/disable HP QuickLook 2 (enabled by default).
●
Enable/disable Virtualization Technology (select models
only; disabled by default).
●
Enable/disable Dual Core CPU (enabled by default).
●
Enable/Disable Unified Extensible Firmware Interface
(UEFI) mode (enabled by default).
Computer Setup in Windows Vista and Windows XP 121
