QD2040-ADV/MAX
Embedded Site Communication
Center
Product Manual
Description
The QD2040 Series Embedded Site Communication
Center is designed to act as a stand-alone web enabled
server or as a gateway working in conjunction with a
central Ubiquity server. The QD2040 offers an on-site
interface that can remotely program, schedule and
monitor the controller network through a browser. Users
can network the QD2040 utilizing an Ethernet port or
through dial-up. Loop Control and energy metering of
demand and consumption is standard to the QD2040 as
well. The QD2040-ADV (Advanced) includes standard
functionality plus support for the Superzone Commercial
Zoning System (Superzone CZS). The QD2040-MAX
(Maximum) provides standard functionality plus support
for VAV systems, the Superzone CZS, and Zigbee
Wireless.
Features
• Integrated Web Server with 512 MB of Ram and 80 GB of
Storage Capacity
• Integrated 10/100 ethernet controller with firewall
capabilities
• Integrated Modem for dial-up or PPP (Dial-up ISP)
connections
• Embedded simple interface to program and monitor the
Controller Network
• Standard fallback alarming local to the device
• Energy Metering and Monitoring with a Modbus Veris Meter
• Interface into Ubiquity
• Integrated controller programming and scheduling
• Remotely upgradable firmware
• User definable communication cycles and packet sizes
• SSL (Secure Socket Layer) enabled web pages
• Dial-in support to interface with a controller network without
an internet connection
• Integrated controller addressing
• Multi-port network capabilities
• Energy demand limiting and, curtailment (requires controller
firmware 1.4 or later)
• Supports all TCS Basys Controllers
Contents
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Material List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Control Network Wiring& Setup . . . . . . . . . . . . . . . . . 4
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Ubiquity Systems Software . . . . . . . . . . . . . . . . . . . . 8
Checkout and Troubleshooting. . . . . . . . . . . . . . . . . . 8
LED Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Material List
• QD2040 Embedded Site Communication Center
• Phone cable
• Power cord
• QD2040 EZ Installation & Programming Instructions
• 7 ft CAT 5 Crossover Patch Cable
(used for connecting directly from PC to QD2040
only)
