4. Unfolding the Transformer
▶ Keep the base of the unit on
the flat surface. From the folded
position, while holding the legs down,
gently pull the arm of the Transformer
to a vertical position. (See Figure 2)
▶ Pull the arm that is connected to the
camera head slowly to a horizontal
position. (See Figure 3) Upon unfolding
the Transformer the LED light and unit
should automatically turn on.
▶ Once the unit is open, grasp the feet
and move them away from each other.
Next rotate the camera head toward the
object you wish to magnify.
(See Figure 4)
▶ To fold back to starting position
repeat steps in reverse.
5. Turning the power on and off
The Transformer will always be off in
the closed position. Upon unfolding the
Transformer the LED light and unit
should automatically turn on in reading
mode. If you wish to turn off the unit
while it is still open, hold down the
Green power button for 3 seconds until
LED light and unit turn off.
(See Figure 1)
Figure 1
Figure 2
Figure 3
Figure 4
