Congratulations on your purchase of the Transformer. Enhanced Vision products are designed to give you the highest quality and convenience available. Transformer is the most flexible and portable solution for reading, writing and viewing magnified images at any distance. Compatible with popular magnification software and windows operating systems, Transformer’s unique compact design is perfect for school, work, or home.
FCC COMPLIANCE NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Chapter 1: Safety Precautions General guidelines…………………...……….………….6 Transportation …………………..…………….………… 7 Care & Maintenance ………………………….………... 8 Chapter 2: System Requirements System Requirements …………...………….….………9 Chapter 3: Getting Started Setting up your Transformer ……………………….10-11 Software installation ………………………………...12-13 Charging…………………..…………………….………. 14 Keyboard Controls ………..….….…………………….. 15 Chapter 4: Package Contents & Controls Package Contents & Controls…….…..
Using the Freeze ………………………….…………. 27 Using the Rotate ………………………….………..……27 Color select mode……………..…………………………28 Upgrading your software ……….……………….…… 28 Chapter 6: Using the menu Accessing the menu ……………….………...…….….. 29 Enable/Disable Window markers ……….……….…... 30 Adjusting the Size/Position of Selected marker...........31 Adjusting the Color Balance ……………………..…… 32 Changing Favorite color modes …………….…………33 Changing View Modes …………………….….………..34 Changing Languages ………………….……………….
SAFETY PRECAUTIONS For your safety and to obtain the most benefit and life from the Transformer, please read these important safety precautions carefully. General guidelines for use: ▶ Use the Transformer on a stable, level surface such as a solid desk or table, according to its intended design specifications. ▶ Always use the power supply provided with your package.
▶ Do not use the Transformer near open flames, flammable materials or liquids. Transportation: ▶ Transformer comes with a convenient carrying case for transport. To prevent the unit from being accidentally dropped and damaged, always return the Transformer to the carrying case while not in use. ▶ This product is intended to be used as a portable device. Please use care when connecting/disconnecting cables and accessories.
Susceptibility to Interference: There may be temporary performance degradation of the Transformer when subjected to a strong magnetic and/or radio-frequency field, electrostatic discharge or transient electrical noise. An electrostatic discharge (caused by static electricity) may cause image distortion. If this happens, switch the unit off and try moving the unit to a different location. ▶ This product contains moving parts.
SYSTEM REQUIREMENTS Laptop or Desktop PC Minimum Requirements: Operating Systems: Supported platforms for our Viewer application: • * Windows 7 (32-bit & 64-bit) Minimum requirements: • • • • • • OS: *Windows 7 Processor: Intel Pentium M 1.5 GHz Memory: 512 MB USB 2.0 (high-speed): 1 available port required Graphics card: Must support DirectX 8.
GETTING STARTED 1. Setup the Transformer Remove the Transformer from the case. Place the unit on a flat, level surface such as a table or desk. 2. Connect the AC power Figure 1 Connect the attached power cord to an available wall outlet. (See Figure 1) *To offer additional protection during an electrical storm, a surge protector may also be used and is recommended.* 3a. Connecting USB to Computer Connect USB cable that was provided to the back of your Transformer.
4. Unfolding the Transformer ▶ Keep the base of the unit on the flat surface. From the folded position, while holding the legs down, gently pull the arm of the Transformer to a vertical position. (See Figure 2) ▶ Pull the arm that is connected to the camera head slowly to a horizontal position. (See Figure 3) Upon unfolding the Transformer the LED light and unit should automatically turn on. ▶ Once the unit is open, grasp the feet and move them away from each other.
Software Installation for Transformer USB If this is your first time using the Transformer, use the following instructions to install the viewer software. 1. Start up your PC as normal. Plug in the USB into your PC and the opposite end into your transformer. 2. A pop-up window appears if you are operating on Windows 7, select open files from the pop-up menu (See figure 1), go to step 3c. Figure 1 Figure 2 3. If a pop-up doesn’t appear: a) Navigate to your start menu and go to “My Computer”(See figure 2).
Figure 3 Figure 4 4. Once the setup wizard appears on screen, click to highlight “EVVAutoLauncher.exe” then click “Next”. (See figure 4) *If already installed EV Viewer will automatically launch. 5. Choose the destination folder to install the software and click on the “Next” button to continue the installation process (See figure 5). Figure 5 6. A ready to install screen will appear, click “Install” to continue the installation. 7. The software will start installing, this should take aprox.1 min. 8.
CHARGING TRANSFORMER The Transformer Magnifier comes preinstalled with the battery inside the unit. To charge the battery off the Transformer Magnifier, simply plug the included AC Adaptor to an available electrical outlet and then into the dongle labeled “PWR”. (See Page 12, 17-18) Note: The included USB Cable DOES NOT charge the Transformer. The battery will take approximately 4 hours to fully charge. The Transformer Magnifier will provide up to 4 hours of usage when fully charged.
Keyboard Controls Switch Zoom+ Keyboard Up Arrow Zoom - Down Arrow FREEZE F H V Escape M Enter L MODE LED On/Off FIND Rotate Comments Zooms in and navigates menu. Zooms out and navigates menu. Freeze Markers (Horizontal) Markers (Vertical) Enter menu Next color Mode Select menu item Light On/Off Space Bar R F5 F6 F7 F8 Shift + Arrow F1 Find Rotate Save image View saved image Full screen / hide Change window position.
PACKAGE CONTENTS & CONTROLS Please note the locations of the following controls on your Transformer: A. Camera: Rotates 330˚ B. Find Button C. Camera Lens: Open lens for distance viewing D. LED Light E. Battery Compartment (Integrated Charger) F. Rotate Button: Rotates current image. G. Green power button: Turns unit on/off H. Mode Button: Changes current favorite color mode I. Zoom Wheel: Magnifies image, and navigates menu J. Freeze Button: Freezes image on-screen K. USB Input L.
A B D C E F G H 1 I J M N 2 3 L 4 K 5 O Chapter 4 Package Contents & Controls 17
USING THE TRANSFORMER Now that your Transformer is installed and ready to operate we can focus on the ease of use, and functionality available to you. Viewing Mode The Transformer can be used to view objects at a distance, up close, or anywhere in between. To change viewing mode, simply turn the position of the camera by rotating it on the arm. Your Transformer has a memory feature that allows each viewing mode to be remembered by the 3 different viewing angles.
Adjusting the Viewing Mode The Transformer Camera rotates 330 degrees, providing unsurpassed flexibility for the visually impaired. Do NOT force the camera beyond its 330-degree angular range as this may damage the unit. 330 Distance Viewing Mode ˚ The camera can rotate forward to capture people, objects and scenery. Be sure to open the Reading Lens for Distance Viewing (See Figure 1). The LED light should automatically turn off in this position.
Reading and Writing Mode The Camera can be adjusted downward for reading, writing and enjoying crafts or other hobbies (See Figure 1). This makes it ideal for classroom use. When the camera is rotated downward it is best to close the zoom lens for optimal viewing clarity. Figure 1 Figure 2 Viewing Position While in Reading and Writing mode the Transformer has the flexibility to be used in three different positions, Right, Forward, and Left.
Self Viewing Mode The Camera can be rotated backwards to provide you with the equivalent of a full-length mirror. In this position, you can use the Transformer to help you put on make-up, shave or perform other personal hygiene. Be sure to open the Reading Lens for Self Viewing. (See Figure 1) The LED light should automatically turn off in this position. However, if you prefer for it to be on, simply press the Green power button.
Adjusting the Video Window Divider (Computer Connection Only): Press the [F8] function key on your PC keyboard to toggle the position of the on-screen camera window. Each press of the [F8] key will rotate the camera window position clockwise (left, top, right or bottom, or full screen). After cycling through all five camera window positions, pressing the [F8] key a sixth time will exit the camera viewing window, returning you to your full screen PC desktop.
Once you’ve chosen the position of the on-screen camera image, use the following procedures to adjust the width/ height of the video window divider, relative to your PC display: • If the on-screen camera image is positioned to the left or right of your display, hold down the [SHIFT] button while pressing either the left or right arrow keys on your PC keyboard to increase or display. decrease the width of the video divider window.
Capturing a Still Image (Computer Connection Only): The Viewer application allows you to capture a still photo (or “snapshot”) of the camera image. This is especially useful in school or work settings, where it may be desirable to magnify and store text that is located on an distant object (i.e. chalkboard or dry erase board) and later recall the image (homework assignments, etc.). Use the following procedure to use the Image Capture feature: 1) Focus on either a near or distant object.
Viewing a Stored Image (Computer Connection Only): 1) Press the [F6] function key on your PC keyboard. to open a previously stored image. The standard “Open” dialog box will appear. 2) Choose the directory in which the stored file is located and select “Open” to view the image.
Using the Find The Transformer Find feature can help you quickly identify where you are currently magnified on a page, or can easily locate a specific part of an object you want to view more closely. NOTE: You cannot use object Find if you are magnified at 1x. While magnified, press and hold down the Find button on the Figure 1 camera head (See Figure 1) 1.
Using the Freeze Function Freeze allows you to take a snap shot of what the Transformer is magnifying in order for you to have extended time to view the image. This is particularly helpful when taking notes in a classroom. The following directions can be used to apply the Freeze mode using the Transformer only: 1. Press the Freeze button to activate Freeze mode (See Figure 1). 2. To release the Freeze mode, press any key or change the viewing angle.
Color Select Mode The Transformer was designed to provide optimum viewing for people with certain visual conditions by offering a range of choices in both text and background colors. Use the Mode key (See Figure 1) to toggle between full color viewing, enhanced positive, enhanced negative, and your 6 favorite color select modes. The 6 favorite color select modes can be modified to any of the 28 color select options by following the instructions provided on page 33.
USING THE MENU FOR USB AND VGA Accessing the Menu ▶ You can access the menu by pressing and holding the Freeze button on arm of the Transformer for 3 seconds. ▶ Once the setup menu shows on-screen, use the Zoom wheel + or - to scroll through the functions. To activate one of the functions press Mode while it is highlighted.
Enabling/Disabling Line & Window Markers Line & Window Markers are used to frame an image between two horizontal lines. These lines may be used as a reading guide for long passages of text, as a guide to help keep your place as you move from one side of the page to the other, or just to make writing easier. The following directions can be used to Enable/Disable Line & Window Markers 1. Press and hold the Freeze button for at least 3 seconds or until setup menu shows on-screen. 2.
Adjusting the Size/Position of the Selected Marker The following directions can be used to adjust the Size/ Position of the Line or Window Marker: 1. Make sure the Line/Window marker is currently Enabled. (Refer back to page 30 if you are not sure how to do this) 2. To increase or decrease Line/Window marker size scroll with the Zoom wheel + or - to Marker size on the setup menu (See Figure 1) and press the Mode button. 3. Use the Zoom wheel + or - to increase or decrease the size of the Line/Window marker.
Adjusting the Color Balance Color is often affected by the lighting used in a room. The Transformer Color Balance control allows you to achieve optimum clarity. The following directions can be used to adjust the Color Balance: 1. Press and hold the Freeze button for 3 seconds until setup menu shows on-screen 2. Scroll with the Zoom wheel + or - and press Mode on the desired Color button.
Changing Favorite Color Modes The Transformer provides 28 selectable color modes, and allows selecting up to 6 favorites for use, as described on page 28. The following directions can be used to change the favorite color modes on your Transformer: 1. Press and hold the Freeze button for 3 seconds until the on- screen menu shows up. Figure 1 2. Scroll with the Zoom wheel + or to the color mode selection and press the Mode button. (See Figure 1) 3.
Changing Viewing Modes VGA to USB 1.) Plug in the included USB cable to the Transformer dongle labeled “USB” and to an available USB port on the computer. 2.) Run the EV Viewer software on your computer. The Transformer will not power on unless the EV Viewer software is running. USB to VGA 1.) Unplug the USB from the computer and from the dongle of the Transformer. The Transformer will be in standby mode 2.) Plug in the included VGA cable to the dongle labeled “VGA” and to the VGA monitor. 3.
Changing Languages VGA Mode 1. Press and hold the Freeze button to enter the Menu 2. Using the Scroll Wheel, Highlight “Product Information” 3. Press the Mode Button once to select the Product Information Sub Menu 4. Using the Scroll Wheel, select “Language” and press the Mode button once. 5. Using the Scroll Wheel, select the desired language and press the Mode button once. USB Mode The Transformer, while in USB mode, will automatically detect the language that is set on your Microsoft Windows PC.
TROUBLESHOOTING No power to the unit Can you power the unit using the included AC adaptor? Is the power supply properly connected to a surge protector or an AC outlet? (page 15) NOTE: A Viewer software reset may be necessary in the event of a power surge. Video image on Computer screen is blurry not clear or slow Clean the LCD display and/or camera lens using a cleaning cloth.
SPECIFICATIONS Features: • • • • • • • Lightweight, portable design 330˚ adjustable camera head 6 user favorite color modes (with 28 to choose from) 28 available color modes Magnification 2.45X up to 30X (Based on a 17” monitor) Image “Freeze” mode Integrated battery charger Battery: • D-Li1, Li-ion 2 Cell, 7.4V, 2,600mAh Rechargeable (included in package) Camera: Digital CCD, Autofocus Physical Dimensions: ~ 10”L x 3.65”W x 3.25”H (closed) ~ 13”L x 10.5”W x 9.
Environment: • • Operating Temperature : 32˚ – 104˚F (0˚ – 40˚C) Humidity 10-90% (non-condensing) Storage temperature : -4˚ – 140˚F (-20˚ – 60˚C) Estimated Charge times (using rechargeable battery): ~4 hours maximum * Note: Only with use of Enhanced Vision Battery **All times listed are approximate. Actual Charging and Usage times may vary depending on the life cycle remaining on the batteries, type and current rating of batteries used, LCD brightness setting, LED Mode and other variable factors.
WARRANTY INFORMATION Enhanced Vision Transformer Warranty Policy Enhanced Vision products are designed to give you the highest quality image, convenient features, ease of use and reliable service. The Transformer has been inspected and tested prior to shipping. Enhanced Vision warrants the Transformer against defects in material and workmanship under normal use for two years from the date of original purchase.
▶ You must provide proof of purchase, bearing the date of purchase, in order to receive warranty service. ▶ Anyone using this product does so knowingly as summing certain risks, due to the need to utilize vision enhancement devices. Service Process In the event that technical support or repair service is needed, please contact your local Enhanced Vision representative or the Enhanced Vision warranty service center.
OTHER ENHANCED VISION PRODUCTS Pebble HD Pebble HD boasts a new HD camera providing a crisp, clear, colorful, high definition picture. A new ergonomic lightweight compact design makes it the perfect companion whether at home or on the go. Carry Pebble HD in your purse, pocket, or clip it on your belt with the included carrying case. Magnification: 1.25X – 13.
Merlin elite See and hear the difference! Merlin elite is a high performance desktop video magnifier (CCTV), featuring HD and text-to-speech (OCR). High definition color and contrast provides a beautiful, crystal clear picture and vibrant colors. Merlin elite’s unique design allows for a wide field of view, displaying more text on the screen. Magnification: 2.4x - 70x Merlin Ultra HD Merlin ultra HD’s camera technology produces an even truer, more natural image.
Accessories Additional Battery Additional batteries are available for your Transformer. Power Supplies Optional external charger is available for your Transformer. X-Y Mini table Place underneath your Transformer and make reading even easier! Contact Information: (US Office) Phone: (714) 465-3400 Fax: (714) 374-1821 (UK Office) Phone: +44 (0)115 9442317 Fax: +44 (0)115 9440720 (DE Office) Phone: +49 (0) 6078 969827-0 Fax: +49 (0) 6078 969827-33 Technical Support: Main Toll Free (800) 440-9476 ext.
