Technical data

Sample New TCP/IP Services Installation and Configuration
A.2 Sample New Configuration Procedure
If you enable dynamic GATED routing, you will be able to
configure this host to use any combination of the following
routing protocols to exchange dynamic routing information
with other hosts on the network:
Routing Information Protocol (RIP) - Version 1 & 2
Router Discovery Protocol (RDISC)
Open Shortest Path First (OSPF)
Exterior Gateway Protocol (EGP)
Border Gateway Protocol (BGP-4)
Static routes
* Do you want to configure dynamic ROUTED or GATED routing [NO]:
Return
A default route has not been configured.
* Do you want to configure a default route [YES]:
Return
Enter your Default Gateway host name or address: GATE1.BUDGET.ACME.COM
gate1.budget.acme.com is not in the local host database.
Enter Internet address for gate1.budget.acme.com: 10.0.2.66
BIND RESOLVER Configuration
A BIND resolver has not been configured.
Compaq TCP/IP Services for OpenVMS supports the Berkeley Internet Name
Domain (BIND) resolver. BIND is a network service that enables clients
to name resources or objects and share information with other objects
on the network.
Before configuring your system as a BIND resolver, you should
first be sure that there is at least one system on the network
configured as either a BIND primary or secondary server for
this domain.
You can specify a BIND server by its address or name;
however, if specified by name, an entry for it must
exist in the TCPIP$HOST database.
You will be asked one question for each server.
Press Return at the prompt to terminate the list.
Enter your BIND server name: NUMB9.BUDGET.ACME.COM
Return
numb9.budget.acme.com is not in the local host database.
Enter Internet address for numb9.budget.acme.com: 10.0.2.11
Enter your BIND server name:
Return
Creating file TCPIP$ETC:IPNODES.DAT
Creating file TCPIP$ETC:SERVICES.DAT
TCPIP uses timezone information provided by the OpenVMS Operating
System. No additonal timezone configuration is needed for TCPIP
when the operating system is configured correctly.
This section verifies the current OpenVMS timezone configuration.
A warning message (TCPIP-W-) indicates that corrective action should
be taken. TCPIP will appear to operate but components may display
either the wrong time or a time inconsistent with other applications.
%TCPIP-I-INFO, Logical name SYS$TIMEZONE_RULE found.
-TCPIP-I-INFO, Software for automatic Summer/Winter time (TDF) change
-TCPIP-I-INFO, is present.
-TCPIP-I-INFO, Further action to ensure TDF change is not necessary.
%TCPIP-I-NORMAL, timezone information verified
Press Return to continue ...
Return
Compaq TCP/IP Services for OpenVMS Core Environment Configuration Menu
Configuration options:
A–4 Sample New TCP/IP Services Installation and Configuration
