Configuring TCP/IP Services
3.3 Running TCPIP$CONFIG
DYNAMIC ROUTING Configuration
Dynamic routing has not been configured.
You may configure dynamic ROUTED or GATED routing.
You cannot enable both at the same time. If you want
to change from one to the other, you must disable the
current routing first, then enable the desired routing.
If you enable dynamic ROUTED routing, this host will use the
Routing Information Protocol (RIP) - Version 1 to listen
for all dynamic routing information coming from other
hosts to update its internal routing tables.
It will also supply its own Internet addresses to
routing requests made from remote hosts.
If you enable dynamic GATED routing, you will be able to
configure this host to use any combination of the following
routing protocols to exchange dynamic routing information
with other hosts on the network:
Routing Information Protocol (RIP) - Version 1 & 2
Router Discovery Protocol (RDISC)
Open Shortest Path First (OSPF)
Exterior Gateway Protocol (EGP)
Border Gateway Protocol (BGP-4)
Static routes
* Do you want to configure dynamic ROUTED or GATED routing [NO]: YES
Return
* Do you want to enable GATED routing configuration [NO]:
Return
ROUTED option
If you enable the ’supply’ option of dynamic routing,
this host will supply dynamic routing information to
other hosts on the network whether it is acting as an
internetwork gateway or not.
* Do you want this host to supply its dynamic routing information [NO]:
Return
3.3.4.4 BIND Resolver Configuration
The following is sample output for configuring the BIND resolver:
A BIND resolver has already been configured.
BIND Resolver Configuration
Transport: UDP
Domain: budget.acme.com
Retry: 4
Timeout: 4
Servers: island.budget.acme.com
Path: No values defined
* Do you want to reconfigure BIND [NO]:
Return
In this example, no changes are made to the BIND resolver.
3.3.4.5 Time Zone Configuration
The following is sample output for configuring the time zone:
Configuring TCP/IP Services 3–7
