Technical information
7
team
server A800
i
team
server
A800
i
is a workgroup server utilising a single 400MHz Intel® Pentium® II processor or a single 450MHz,
500MHz, 550MHz or 600MHz Pentium® III processor. The
A800
i
extends the existing teamserver range to
accommodate small to medium-sized businesses with cost-sensitive requirements, whilst still providing the high level of
performance and reliability associated with Fujitsu
team
servers
.
Intel Pentium II 400MHz CPU with 512kB 2
nd
level cache or
Intel Pentium III 450MHz, 500MHz, 550MHz or 600MHz CPU with 512kB 2
nd
level cache
High-performance CPU combined with 100MHz System Bus and enhanced I/O subsystem alleviates system
bottlenecks to deliver superior end-to-end system performance
Maximum 41.1GB of IDE or 54GB SCSI disk storage in system cabinet
Motherboard with 440BX chipset supporting up to 1GB SDRAM memory
3 dedicated PCI slots, 1 dedicated ISA slot and 1 shared PCI/ ISA slot
Fujitsu servermanager
providing suite of programs to manage server
Support for industry-standard operating systems: Microsoft® Windows NT® Server 4.0
SCO® UnixWare® 7 and Novell® IntranetWare 4.11
Processor
team
server
A820
i:
Pentium II 400MHz with 512KB integral L2 cache
team
server
A840
ie:
Pentium III 450MHz with 512KB integral L2 cache
team
server
A870
i:
Pentium III 500MHz with 512KB integral L2 cache
team
server
A870
ie:
Pentium III 550MHz with 512KB integral L2 cache
team
server
A870
ix:
Pentium III 600MHz with 512KB integral L2 cache
Intel 440BX Chipset
Memory
1GB ECC SDRAM maximum from 4 DIMM slots (using 4 * 256MB DIMM)
Disks (internal max)
•
Maximum 41.1GB with IDE disks (3 * 13.7GB);
•
Maximum 54GB with SCSI disks (3 * 18GB)
I/O buses
•
3 x dedicated PCI slots
•
1 x dedicated ISA slot
•
1 shared PCI/ISA slot
On-board I/O subsystems
•
10/100 Mbps UTP PCI wake-on LAN Intel 82558 Ethernet controller
integrated onto motherboard
Storage bays
•
3 x 5.25” bays, one occupied by CD-ROM
•
4 bays including 2 of the 5.25” bays (for up to 4 SCSI disks or 3 IDE disks)
one may already be occupied by the system disk
•
1 x FDD bay, occupied by FDD
Storage in standard
configuration
•
1 x 1.44MB 3.5 inch diskette drive
•
1 x IDE CD-ROM drive
Server Management
Suite of products focused on managing server hardware remotely using the standard
SNMP protocol. Integrates with existing network management systems.
Graphics as standard
SVGA AGP Graphics Controller with 4MB video RAM (ATi 3D Rage 2C AGP)
plugs into a dedicated AGP slot on the motherboard (not upgradeable)
Operating system
software
•
Microsoft Windows NT Server 4.0
•
Novell IntranetWare 4.11
•
SCO UnixWare 7
Memory Upgrades
•
64, 128MB and 256MB SDRAM upgrades
Storage Devices
•
4.3GB, 6.4GB, 8.4GB, 10.1GB and 13.7GB IDE hard disk drives
•
4GB Ultra-SCSI disk
•
9GB and 18GB Ultra2/LVD SCSI disks
•
4-8GB DDS-2 4mm internal DAT drive
•
12-24GB DDS-3 4mm internal DAT drive
•
4-8GB Travan 4 tape drive (supported by NT only)
Network Controllers
•
On-board 10/100 Mbps UTP PCI wake-on LAN Intel 82558 Ethernet controller
•
Intel PRO/100+ Server Adapter
Disk Controllers
•
Optional Adaptec AHA2940UW Single Channel S/E PCI Adapter
UPS
•
APC (American Power Conversion)
Dimensions & Weight
Height, Width, Depth (410 x 190 x 435mm)
Weight: 16Kg
Standard warranty
Contact Fujitsu Sales in your country for further details of the warranty that is offered.
team
server 800 Series
