Technical information

43
team
server M700
i
The
team
server M700
i
servers are high performance servers utilising Pentium Pro processor technology from Intel.
•
Choice of single, dual, quad and 6-way Processor Models. Upgrade to triple processor model also available.
•
10/100 Mbps Ethernet and two Ultra/Wide SCSI controllers on motherboard
•
6 dedicated PCI and 4 dedicated EISA slots
•
A Fujitsu-designed motherboard giving up to 4GB ECC EDO memory to maximise database performance
•
Up to 9 hot swap disks in the base system cabinet, giving up to 162GB
FEATURE M750i M752i M754i M756i M794i M796i
Pentium Pro Processors
1 x 200MHz
512KB
2 x 200MHz
512KB
4 x 200MHz
512KB
6 x 200MHz
512KB
4 x 200MHz
1MB
6 x 200MHz
1MB
Memory (Standard)
0MB 0MB 0MB 0MB 0MB 0MB
Chip Set
Fujitsu RCC
Cache
512KB or 1MB second-level cache per processor
ECC Memory
Maximum 4 GB DIMMs. The amount that can be used will be dependent on the
Operating System. (Currently 512MB for SCO OpenServer Release 5)
Disks (Internal Max)
9 (for any restrictions on number of disks, see
PD-SR-0019
)
I/O buses
Dual bus PCI/EISA architecture
6 x dedicated PCI slots
4 x dedicated EISA slots
On-board I/O
subsystems
2 x PCI-Adaptec 7880 Single-Ended Ultra SCSI controllers for Internal Connection,
integrated onto motherboard. Communicates with system via the PCI bus
10/100 Mbps Fast Ethernet (Intel EtherExpress PRO/100B) for UTP (unshielded
twisted-pair) cable
Standard I/O Ports
2 x Asynchronous Serial (COM) Ports
1 x Parallel (LPT) port, capable of operating in ECP or EPP modes
Mouse and PS/2 Keyboard Ports
Storage bays
3 x 5¼ inch format, half-height external device bays (1 occupied by
CD-ROM as fitted as standard)
1 x 3½ inch format, 1 inch height external device bay (occupied by a diskette drive)
Storage in standard
configuration
1 x 1.44MB 3½-inch diskette drive
1 x SCSI-2 CD-ROM drive
Server Management
•
Suite of products focused on managing server hardware remotely using the
standard SNMP protocol. Integrates with existing network management systems.
For more information see
PD-MW-0019
.
Graphics as standard
•
SVGA PCI graphics adapter (Cirrus GD54M40, 1MB DRAM) integrated onto the
motherboard
Operating system
software
Operating systems supported:
•
SCO UnixWare 2.1.2
•
Microsoft Windows NT Server 4.0
•
Novell IntranetWare 4.11
†
•
Citrix WinFrame 1.7
†
IntranetWare and OpenServer are not supported on
M756
i
or
M796
i
Databases
Oracle, Informix, CA-Ingres, Sybase and SQL Server
Redundant Power
Supply
Two power supplies are included as standard in the base system cabinet. The
Redundant Power Supply is an optional product which provides resilience in the case
of failure of one of the standard PSUs. It can be hot-swapped.
Standard warranty
Contact Fujitsu Sales in your country for further details of the warranty that is offered.
